HDMI 1X4 splitter supports 4K2K3D HDMI one -four splitter
Sku
LZRN0040
$13.98
| Qty | 1 | 3 | 10 | 20 | 40 |
|---|---|---|---|---|---|
| Price | $15.67 | $15.29 | $14.75 | $14.28 | $13.98 |
Qty
Sales Ends In
- Buyer Protection
- Full Refound if you don't receive your order
- Full or Partial Refund,If the item is not as described
Product characteristics:
- L 1 channel HDMI signal input, allocated to 4 channels HDMI output.
- HDMI supports 4K/30Pps at the highest resolution and 3D.
- L Supports 24 bits/dark 30 bits/36 bits.
- 1 Supports Blu-ray DVD24/50/60Fps/HD-DVD/xvYCC.
- Support audio format: DTS-HD/Dolby-trueHD/LPCM7.1/DTS/DOLBY-AC3/DSD.
- L Supports signal timing reorganization.
- Using AWG26 HDMI 1.4b standard cable, the input transmission distance can reach 7 meters, and the output transmission distance can reach 8 meters.
- Lossless and delay-free transmission of audio and video.
- The panel LED lamp clearly shows the usage status of the distributor.
- L Easy to install and use.
Product parameters:
- HDMI input and output resolution..................... up to 4K/30Fps
- HDMI supports video color formats............... 24 bits / dark 30 bits / 36 bits
- HDMI supports audio format... DTS-HD/Dolby-TrueHD/LPCM7.1/DTS/Dolby-AC3/DSD
- Maximum transmission bandwidth of HDMI................................. 300MHz
- Maximum transmission speed of HDMI.................................... 10.2 Gbps
- Input and output TMDS signals................................. 0.5-1.5Vp-p (TTL)
- Input and output DDC signals.................................... 5Vp-p (TTL)
- HDMI input cable length........................ Less than 7m AWG26 HDMI standard line
- HDMI Output Cable Length..................... Less than 8m AWG26 HDMI Standard Line
- Maximum operating current............................................. 300 mA
- Specifications of power adapters............ AC 100V-240V 50/60HZ, DC 5V/1A
- Working Environment Temperature....................................... - 10~+55 Temperature
- Storage temperature....................................................... -20~+60 C
- Working humidity.................................... 10-90% RH (no condensation)
- Product material....................................... Aluminum alloy
- Shell dimensions of products.............................. 160 *105 *26 (mm)
- Color: black
- Size: approximately 16 *10.5 *2.6 cm
- Weight: about 100g
Package Content
- 1x HDMI 1X4 splitter 4 K
- USB Power cord
- User's Manual
Note: shooting light and different displays can color the item in the photo a little different from the real thing. The measurement error allowed is +/-1 -3 cm.
